8S-16S 200A BMS for Energy Storage &3-Wheeled Vehicle &Car Air conditioner &Golf Cart &Motorcyle &Jet Powered Surfbaord

  LF LI Model Number AY-L10S200A-ES002 (3S-10S) Communication Interface RS485/CAN/BLE Charging voltage DC：12.8V-32VCC/CV（3.2V/Cell)4s-10s DC：12.6V-42VCC/CV（4.2V/Cell)3s-10s Maximal continuous charging current 200A Maximal continuous discharging current 200A Current consume in normal operation ≤15mA Current consume in sleep operation ≤150uA Balance voltage for single cell 3.5±0.05V 4.0±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 220±3A Discharge Over current detection current 1 400±3A Discharge Over current detection current 2 500±3A Short Protection YES SOC 5%~8% Technical Specification Size L180 * W90 * T25 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance YES Heater  YES Braking Resistors NO Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board YES Bluetooth mode YES 4G YES GPS YES Optional Configuration

18S-24S 200A BMS for Golf Cart &Energy Storage &3-Wheeled Vehicle &Motorcyle

  LF LI Model Number AY-LS24S200A-H245 (18S-24S) Communication Interface RS485/CAN Charging voltage DC：51.2V CC/CV（3.2V/Cell) 16s DC：67.2V CC/CV（4.2V/Cell) 16s Maximal continuous charging current 200A Maximal continuous discharging current 200A Current consume in normal operation ≤15mA Current consume in sleep operation ≤150uA Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 220±3A Discharge Over current detection current 1 400±3A Discharge Over current detection current 2 500±3A Short Protection YES SOC 5%~8% Technical Specification Size L245 * W85 * T18 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance / Heater  / Braking Resistors / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board / Bluetooth mode YES 4G / GPS / Optional Configuration

16S-20S 110A BMS for Golf Cart &Energy Storage &3-Wheeled Vehicle &Motorcyle &Jet Powered Surfbaord

  LF LI Model Number AY-LS20S110A-H165 (16S-20S) Communication Interface RS485/CAN Charging voltage DC：51.2V~64VCC/CV（3.2V/Cell)16s~20s DC：67.2V~84VCC/CV（4.2V/Cell)16s~20s Maximal continuous charging current 110A Maximal continuous discharging current 110A Current consume in normal operation ≤20mA Current consume in sleep operation ≤100uA Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 130±3A Discharge Over current detection current 1 250±3A Discharge Over current detection current 2 350±3A Short Protection YES SOC 5%~8% Technical Specification Size L165 * W100 * T17 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance / Heater  / Braking Resistors / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board / Bluetooth mode / 4G / GPS / Optional Configuration

16S-20S 90A BMS for Golf Cart &Energy Storage &3-Wheeled Vehicle &Motorcyle &Jet Powered Surfbaord

  LF LI Model Number AY-LS20S90A-H150 (16S-20S) Communication Interface RS485/CAN Charging voltage DC：51.2V~64VCC/CV（3.2V/Cell)16s~20s DC：67.2V~84VCC/CV（4.2V/Cell)16s~20s Maximal continuous charging current 90A Maximal continuous discharging current 90A Current consume in normal operation ≤15mA Current consume in sleep operation ≤150uA Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 110±3A Discharge Over current detection current 1 180±3A Discharge Over current detection current 2 280±3A Short Protection YES SOC 5%~8% Technical Specification Size L150 * W76 * T17 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance / Heater  / Braking Resistors / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board / Bluetooth mode / 4G / GPS / Optional Configuration

7S-24S LFP\NMC\LTO|Na-ion 300A BMS for Golf Cart &Energy Storage &3-Wheeled Vehicle &Motorcyle & Parking Air Conditioner

LF LI Model Number AY-L24S300A-ES001 (7S-24S) Communication Interface RS485/CAN/UART Charging voltage DC：22.4V~76.8VCC/CV（3.2V/Cell)7s~24s DC：29.4V~84VCC/CV（4.2V/Cell)7s~20s Maximal continuous charging current 300A Maximal continuous discharging current 300A Current consume in normal operation ≤15mA Current consume in sleep operation ≤150uA Balance voltage for single cell 3.5±0.05V 4.0±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 320±3A Discharge Over current detection current 1 600±3A Discharge Over current detection current 2 800±3A Short Protection YES SOC 5%~8% Technical Specification Size L206 * W162 * T40 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance YES Heater YES Braking Resistors YES Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge 15℃ Release temperature( low temperature protection) 10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range 40~+85℃ Storage Temperature Range 40~+125℃ Temperature Parameter LCD display screen YES LED light board TES Bluetooth mode YES 4G YES GPS YES Optional Configuration

Price: $40-$55

18S-24S 200A BMS for Golf Cart &3-Wheeled Vehicle &Motorcyle

  LF LI Model Number AY-CX24S200A-H093 (18S-24S) Communication Interface RS485/CAN Charging voltage DC：57.6V~76.8V CC/CV（3.2V/Cell)18s-24s DC：75.6V~84 CC/CV（4.2V/Cell)18s-20s Maximal continuous charging current 200A   Maximal continuous discharging current 200A   Current consume in normal operation ≤15mA   Current consume in sleep operation ≤150uA   Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 220±3A   Discharge Over current detection current 1 400±3A   Discharge Over current detection current 2 500±3A   Short Protection YES   SOC 5%~8%   Technical Specification size L235 * W100 * T16 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance  / Heater  / Braking Resistors  / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection） 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen / LED light board / Bluetooth mode YES 4G / GPS / Optional Configuration

20S 200A BMS for Golf Cart &3-Wheeled Vehicle &Motorcyle

Model Number AY-CX20S200A-H105(20S) Communication Interface RS485 Charging voltage DC：64V CC/CV（3.2V/Cell) 20s DC：84V CC/CV（4.2V/Cell) 20s Maximal continuous charging current 200A Maximal continuous discharging current  200A Current consume in normal operation ≤15mA Current consume in sleep operation  ≤150uA Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 120±3A Discharge Over current detection current 1 200±3A Discharge Over current detection current 2  300±3A Short Protection  YES SOC 5%~8% Technical Specification size  L181 * W86 * T16 mm NTC   10K Temperature switch / ℃(the batteries temperature) Weak currentswitch YES Active balance / Heater / Braking Resistors / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge – 15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board  / Bluetooth mode YES 4G  / GPS  / Optional Configuration

20S 100A BMS for Golf Cart &Energy Storage &3-Wheeled Vehicle &Motorcyle

  LF LI Model Number AY-CX20S100A-H092 (20S) Communication Interface RS485 Charging voltage DC：64V CC/CV（3.2V/Cell) 20s DC：84V CC/CV（4.2V/Cell) 20s Maximal continuous charging current 100A Maximal continuous discharging current 100A Current consume in normal operation  ≤15mA Current consume in sleep operation  ≤150uA Balance voltage for single cell 3.6±0.05V 4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current 120±3A Discharge Over current detection current 1  200±3A Discharge Over current detection current 2  300±3A Short Protection YES SOC  5%~8% Technical Specification Size L181 * W86 * T16 mm NTC 10K Temperature switch / ℃(the batteries temperature) Weak current switch YES Active balance / Heater / Braking Resistors  / Other Parameter Low temperature protection when charge 0℃ Release temperature( low temperature protection) 5℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection) -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection) 55℃ Operating Temperature Range -40~-85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen / LED light board / Bluetooth mode YES 4G / GPS / Optional Configuration

8S 200A BMS for Golf Cart &3-Wheeled Vehicle &Motorcyle

  LF LI Model Number     AY-CX8S200A-H104 (8S) Communication Interface     RS485 Charging voltage      DC：25.6V CC/CV（3.2V/Cell) 8s DC：33.6V CC/CV（4.2V/Cell) 8s Maximal continuous charging current    200A Maximal continuous discharging current     200A Current consume in normal operation     ≤15mA Current consume in sleep operation   ≤150uA Balance voltage for single cell       3.6±0.05V  4.2±0.05V Over charge detection voltage 3.65±0.05V 4.25±0.05V Charge Over current detection current  220±3A Discharge Over current detection current 1 400±3A Discharge Over current detection current 2 500±3A Short Protection   YES SOC  5%~8% Technical Specification Size L165 * W80 * T16 mm NTC 10K Temperature switch  / ℃(the batteries temperature) Weak current switch YES Active balance   / Heater YES Heater   / Other Parameter Low temperature protection when charge  0℃ Release temperature( low temperature protection)   0℃ Over temperature protection when charge 60℃ Release temperature( over temperature protection) 55℃ Low temperature protection when discharge -15℃ Release temperature( low temperature protection)  -10℃ Over temperature protection when discharge 65℃ Release temperature( over temperature protection)  55℃ Operating Temperature Range -40~+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen YES LED light board  / Bluetooth mode YES 4G   / GPS  / Optional Configuration
