24V LiFePO4 Battery Pack Item Rating Battery Type LiFePO4 Nominal Battery Voltage 24V Nominal Capacity 100Ah Nominal Energy(25℃,0.2C) 2400Wh Charging Current 50A Discharging Current 10A Charge Voltage 28.0V~28.8V Max Charging Current 100A Max Discharging Current 200A Service life more than 3000 cycles Working Temperature Range Charge: 0℃–+45℃Discharge: -20℃–+60℃ Storage Temperature 0℃–+45℃ Water Dust Resistance IP65 Packing Customized Basic Solution Over Charge Protection,Over Discharge Protection,Over Current Protection,Over Voltage Protection,Under-Voltage Protection,Temperature Protection,Short Circuit Protection Dimension L522*W238*H218mm Weight Approx.20kg - AYAA TECHNOLOGY CO., LTD
Item | Rating |
Battery Type | LiFePO4 |
Nominal Battery Voltage | 24V |
Nominal Capacity | 100Ah |
Nominal Energy(25℃,0.2C) | 2400Wh |
Charging Current | 50A |
Discharging Current | 10A |
Charge Voltage | 28.0V~28.8V |
Max Charging Current | 100A |
Max Discharging Current | 200A |
Service life | more than 3000 cycles |
Working Temperature Range | Charge: 0℃–+45℃ Discharge: -20℃–+60℃ |
Storage Temperature | 0℃–+45℃ |
Water Dust Resistance | IP65 |
Packing | Customized |
Basic Solution | Over Charge Protection,Over Discharge Protection,Over Current Protection,Over Voltage Protection,Under-Voltage Protection,Temperature Protection,Short Circuit Protection |
Dimension | L522*W238*H218mm |
Weight | Approx.20kg |
